Pottinger HIT HT 17160 Tedder
Whether tedding silage or hay, on level ground or hillsides - POTTINGER HIT tedders get the job done perfectly. Innovative DYNATECH rotor technology ensures a clean and tidy spread pattern with maximum forage conservation. As you would expect from PÖTTINGER the tedders ground tracking works perfectly and provides ideal conditions for harvesting high quality forage.
56’5” Working width
9’6” Transport width
16 Rotors
480/55-17 Main wing tires
6 Spline 1-3/8” PTO shaft
Fence line kit installed
100 HP minimum
Whether tedding silage or hay, on level ground or hillsides - POTTINGER HIT tedders get the job done perfectly. Innovative DYNATECH rotor technology ensures a clean and tidy spread pattern with maximum forage conservation. As you would expect from PÖTTINGER the tedders ground tracking works perfectly and provides ideal conditions for harvesting high quality forage.
56’5” Working width
9’6” Transport width
16 Rotors
480/55-17 Main wing tires
6 Spline 1-3/8” PTO shaft
Fence line kit installed
100 HP minimum
Whether tedding silage or hay, on level ground or hillsides - POTTINGER HIT tedders get the job done perfectly. Innovative DYNATECH rotor technology ensures a clean and tidy spread pattern with maximum forage conservation. As you would expect from PÖTTINGER the tedders ground tracking works perfectly and provides ideal conditions for harvesting high quality forage.
56’5” Working width
9’6” Transport width
16 Rotors
480/55-17 Main wing tires
6 Spline 1-3/8” PTO shaft
Fence line kit installed
100 HP minimum
-
When it comes to tedding quality, the diameter of the rotor is often the subject of discussion. In terms of forage quality, however, there is a lot to be said for small rotors. Small rotors adapt ideally to bumpy ground and reduce the amount of crude ash entering the forage. They pick up smaller portions of crop, resulting in neater forage handling. You do not have to spread the forage so widely, which results in an exact spread pattern with homogeneous lateral distribution. They can be operated at lower speeds because they do not have to spread the forage as far. That is how disintegration losses can be avoided.
-
In addition to using small rotors, PÖTTINGER goes one step further to further increase forage quality. Curved, sweeping tine arms ensure that the tines are guided dynamically through the crop. The forage is picked up more easily and more gently than with straight tines, this results in minimising disintegration losses. In addition, the sweeping effect protects the sward. If the tines do contact the ground, the tines are guided in such a way that they have a much gentler effect on the sward and the machine.
-
To achieve the best ground tracking, the MULTITAST jockey wheel system on the pivoting headstock tracks the ground immediately in front of the tine path and responds to each undulation. The jockey wheel ensures an exact working height. You are now able to drive faster and can achieve higher output as a result. On trailed high output tedders, it is the transport chassis that takes over the function of the jockey wheel.
